The KAPPA-M is a dual-input integration and totalizer meter housed in a compact 1/8 DIN format (96 x 48mm panel cutout), featuring a 5-digit red main display and an 8mm green secondary totalizer display. It measures and integrates analog signals over time, supporting two simultaneous inputs with arithmetic operations between them. Available in 115/230V AC (KAPPA-M) and 24/48V AC (KAPPA-M2) variants.
This product has the following features:
-
- Accepts process voltage (0–10V, 0–5V, 0–1V), current (0–20mA), load cell/mV, potentiometer, and shunt inputs.
- Arithmetic operations between inputs including addition, subtraction, multiplication, and division.
- Flexible input scaling via linear, square root, or segmented methods (up to 15 segments), with optional Teach calibration using a live signal.
- Integrator with selectable time base (second, minute, hour, or day) and programmable multiplication factor and Lo-cut threshold.
- 26 programmable logic functions across 4 digital inputs, with output options including 2RE, 4RE, 4OP, ANA, RS2, and RS4.
- Modbus RTU communication protocol supported.
- IP65 frontal protection rating, suitable for panel-mount installation with included sealing gasket and mounting clamps.
